CVC M.2 2280
SATA SSD
128G / 256GB / 512GB / 1024GB / 2048GB
NAND Flash: 3D TLC NAND Flash
Interface: SATA 3 (6Gb/s)
Sequential Read: UP to 550 MB/s
Sequential Write: UP to 510 MB/s
|
Interfaz
|
SATA 3 6.0Gb/s |
|
Capacidad
|
120 GB / 128 GB / 240 GB / 256 GB / 480 GB / 512 GB / 960 GB / 1024 GB / 1920 GB / 2048 GB |
|
Tipo de destello
|
3D TLC |
|
Factor de forma
|
M.2 2280 |
|
Velocidad de lectura secuencial (máx.)
|
550 MB/s |
|
Velocidad de escritura secuencial (máx.)
|
510 MB/s |
|
Lectura/escritura aleatoria IOPS 4K (máx.)
|
65K/75K IOPS |
|
MTBF
|
> 3 million hours |
|
DWPD
|
> 1 (3 yrs) |
|
Consumo de energía
|
1W typ. |
|
Tensión de funcionamiento
|
3.3V |
|
Dimensiones (largo x ancho x alto) mm
|
80mm x 22mm x 1.35mm / 80mm x 22mm x 1.5mm |
|
Temperatura
|
-25°C to 85°C / -40°C to 85°C |
|
Temperatura de almacenamiento
|
-40°C to 85°C |
|
Peso (máx.)
|
6g |
|
Seguridad
|
AES-256 E2E Data Protection LDPC ECC TCG Opal |
|
PLP
|
FW PLP / HW PLP |
|
Características
|
LowPower S.M.A.R.T. |
|
Categoría
|
Industrial |
SSSTC se reserva el derecho de modificar o actualizar cualquier especificación o información en este sitio web sin previo aviso. Toda la información del producto y las especificaciones técnicas son solo de referencia, y las especificaciones reales del producto pueden variar según la disponibilidad actual.
| Modelo | Observaciones |
|---|---|
| CVC-8D120 | Extended Temp (-25°C to 85°C) |
| CVC-8D128 | Extended Temp (-25°C to 85°C) |
| CVC-8D128 | Extended Temp (-25°C to 85°C) |
| CVC-8T128 | Industrial Temp (-40°C to 85°C) |
| CVC-8U128P | Extended Temp (-25°C to 85°C) |
| CVC-8V128 | Industrial Temp (-40°C to 85°C) |
| CVC-8V128P | Industrial Temp (-40°C to 85°C) |
| CVC-8D240 | Extended Temp (-25°C to 85°C) |
| CVC-8D256 | Extended Temp (-25°C to 85°C) |
| CVC-8D256 | Extended Temp (-25°C to 85°C) |
| CVC-8T256 | Industrial Temp (-40°C to 85°C) |
| CVC-8U256P | Extended Temp (-25°C to 85°C) |
| CVC-8V256 | Industrial Temp (-40°C to 85°C) |
| CVC-8V256P | Industrial Temp (-40°C to 85°C) |
| CVC-8D480 | Extended Temp (-25°C to 85°C) |
| CVC-8D512 | Extended Temp (-25°C to 85°C) |
| CVC-8D512 | Extended Temp (-25°C to 85°C) |
| CVC-8T512 | Industrial Temp (-40°C to 85°C) |
| CVC-8U512P | Extended Temp (-25°C to 85°C) |
| CVC-8V512 | Industrial Temp (-40°C to 85°C) |
| CVC-8V512P | Industrial Temp (-40°C to 85°C) |
| CVC-8D960 | Extended Temp (-25°C to 85°C) |
| CVC-8D1024 | Extended Temp (-25°C to 85°C) |
| CVC-8D1024 | Extended Temp (-25°C to 85°C) |
| CVC-8T1024 | Industrial Temp (-40°C to 85°C) |
| CVC-8U1024P | Extended Temp (-25°C to 85°C) |
| CVC-8V1024 | Industrial Temp (-40°C to 85°C) |
| CVC-8V1024P | Industrial Temp (-40°C to 85°C) |
| CVC-8D1920 | Extended Temp (-25°C to 85°C) |
| CVC-8D2048 | Extended Temp (-25°C to 85°C) |
| CVC-8D2048 | Extended Temp (-25°C to 85°C) |
| CVC-8U2048P | Extended Temp (-25°C to 85°C) |
| CVC-8V2048 | Industrial Temp (-40°C to 85°C) |
| CVC-8V2048P | Industrial Temp (-40°C to 85°C) |
Aplicación
Tecnología financiera
FinTech
Automatización industrial
Industrial Automation
Redes & Telecomunicaciones
Networking & Telecom
